AR12
- Functional details
- Parameter
- Video
| Model | Specification | Mark |
| Solution | NT96565+ Front 2K QHD 2560*1440P/30FPS+Rear FHD 1920*1080P/30FPS+11.26 inch+2.5D TP+ GPS +WiFi | |
| Sensor | GC4653 | |
| Screen | 11.26 inch 2.5D Touch Panel | |
| Lens Focal Length | Focal Length=2.9mm | |
| Lens Aperture | 1.55 | |
| FOV | 150°+130° | |
| Video Resolution |
1CH:2K QHD 2560*1440P/30FPS 2CH:2K QHD 2560*1440P/30FPS+1920*1080/25FPS |
|
| Rearcam sensor | GC2053 | |
| Rearcam Focal Length | Focal Length=3.1mm | |
| Rear Lens Aperture | F/NO=2.2 | |
| Rear Fov | 130° | |
| format | MP4 | |
| Comprrssion | MJPG/H.264 | |
| Picture Format | JPG | |
| Battery | Super Capacitor | |
| Connector | Mini USB | |
| Loop Recording | Off，1M，3M，5M，Default：3M | |
| Parking Monitor | Low，Middle，High，Off，Default：Off | |
| WiFi | 2.4G Wi-Fi | |
| G-sensor | Low，Middle，High，Off，Default：Middle | |
| Time Lapse Recording | 1s/5fps 1s/2fps，1s/1fps，Default：Off，Default after turned off ：1s/2fps | working with Hardwire kit |
| GPS | Support external GPS module | |
| Time Watermark | Support | |
| Reversing Aid | Support | |
| Language | Multi Language | |
| Frequence | 50Hz/60Hz | |
| Storage | Max support 128GB, C10 SD Card | |
| Storage Tempreature | -30~80℃ | |
| Working Temperature | -20~65℃ |
