Model
|
M301
|
|
Solution
|
Mstar8339+GC2053+GC2053+GPS+Wi-Fi
|
|
CPU
|
Mstar8339
|
|
SENSOR
|
Sensor name
|
GC2053
|
|
Sensor native resolution
|
2M
|
|
SCREEN
|
Screen size
|
No Screen
|
|
LENS
|
Lens type and layers
|
2G5PIR
|
|
Real angle of view
|
D=124.4° H=102° V=53.4°
|
|
Aperture
|
F/NO=1.8
|
|
Focal length
|
f=3.35mm
|
|
VIDEO
|
Supported video resolution with framerating
|
1CH:2K(2560*1440) @25fps
2CH:2K(2560*1440) @25fps+ 720P @25fps
|
|
Video format
|
MP4
|
|
Compression
|
H.264
|
|
|
Picture format
|
JPG
|
|
Supported photo resolution
|
3M
|
|
USB-function
|
USB-storage
|
yes
|
|
BATTERY
|
Super Capacitor
|
yes
|
|
FUNCTIONS
|
Motion detection
|
yes
|
|
G-sensor
|
yes
|
|
GPS
|
yes,built-in GPS
|
|
WiFi
|
yes
|
|
Voice control
|
yes
|
|
Take a photo in time of video recording
|
yes
|
|
Lock/Unlock a file in time of video recording
|
yes
|
|
LED indicator
|
yes
|
|
Microphone
|
yes
|
|
Speaker
|
yes
|
|
Parking Mode
|
yes, should work with hardwire kits
|
|
Time Lapse
|
yes
|
|
Bluetooth
|
yes
|
|
APP
|
LINGDU
|
|
GPS tracking
|
yes,via APP
|
|
Max ext.storage capacity (TF-card)
|
128G
|
|
TEMP
|
Working temperature range
|
-10℃~ +60℃
|
|
Storage temperature range
|
-20℃~ +70℃
|
|
SIZE
|
Size
|
105.47*64.6*43mm
|
